SAS - Industrial Fume Extractor
Industrial Fume Extractors, manufactured by Sentry Air Systems, can help in providing a highly efficient and effective method of removing hazardous fumes in industrial applications and improving air quality in work environments. Industrial fume extractors use a heavy-duty filtration system to eliminate harmful particles from the air, reducing health risks associated with breathing in toxic fumes and dust.
Industrial fume extraction systems aid in the removal and purification of hazardous fumes and vapors in industrial, and large quantity applications to assist in protecting the respiratory zone of those working with respirable compounds and solutions.
Industrial fume extractors are valuable for a wide variety of applications, used in a multitude of industries that produce highly toxic fumes or dust. Some of these include:
- Machinery industries
- Chemical industries
- Food processing
- Pharmaceutical labs
- Welding
- Metal-working
- Photoelectric industries
- Nail salons
These industries, as well as many others, specialize in techniques that produce fumes and particles that need to be cleaned out of the air to ensure a healthy workplace. Some of the processes that produce noxious particulates and gas include:
- Welding
- Laser cutting or engraving
- Soldering
- Cutting
- Sanding
- Chemical applications
Considering that a large percentage of employees in the workforce spend a good amount of their time at work, it is vital that employers provide a comfortable and clean work environment. Our industrial fume extraction systems, utilizing HEPA filter units to clean the air in indoor workspaces, provide a multitude of benefits to both employees and employers.
- Minimize employee exposure to contaminated air
- Meet your legal obligations
- Heavy Duty Construction
- Low power consumption
- Reliable, low maintenance operation
- No permitting issues for venting outside (ie. EPA air sampling)
Cabinet Dimensions:
- 30” D x 30” W x 42.5” H
Arm Specifications:
- (2)7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood
Total Weight:
Approximately 265lbs without Filters
Approximately 345lbs with Filters Installed
Cabinet Material:
16 ga. carbon steel
Motor:
Fractional Horsepower
Air Volume:
Up to 389 CFM High Per Arm
Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
Sound Level:
65 dba @ 3 ft.
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #61,563,228
Cabinet Dimensions:
- 30” D x 30” W x 42.5” H
Arm Specifications:
- (2) 7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood
Total Weight:
Approximately 360lbs with Filters Installed
Cabinet Material:
16 ga. carbon steel
Motor:
1.5 HP
Air Volume:
Up to 478 CFM High Per Arm
Electrical:
115/1/60, 5.7 amps
Sound Level:
70 dba @ 3 ft.
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #61,563,228
The Micro-Pleat Series 1 Particulate Filters are engineered to be easily cleaned with the use of pressurized air. This form of self-contained cleaning does not require removal of the filters; the operator simply sprays air into the filter media to clean and rejuvenate them while excess dust a nd waste falls into the internal dust pan, allowing for simple and clean debris removal. The included magnehelic gage is an excellent tool for determining filter saturation. Once the pressure levels begin to increase, the operator can clean the filters and the pressure reduction will be noted on the gage.
