SBM - Air Conveying System

Air conveying system takes roots blower as the air source. It is designed specifically for close distance and continuous transporting.

Applicable materials: It is widely used in mining, building materials, coal, chemical, and other industries.

• Variable arrangement of the pipe makes the production workflow process more reasonable.
• The system is sealed and leads to little flying dust, it benefits for environmental protection.
• Few movement parts, convenient maintenance, automatic control can be realized easily
• High efficiency of transportation reduce the cost of packing, loading, and unloading
• Make the material avoid being damped, polluted, damaged, and mixed with other material, the quality of conveying is assured
• Various operation processes can be realized meanwhile for the conveying, such as mixture, crush, grade, dryness cooling, and dust collection.
• Send the material from a couple of places to one place and from one place to a couple of places, realize far distance operation
• For the material with erratic chemical character, can adopt inert gases conveying.

Air conveying system adopts the principle of gas-solid flow fluidization, jet technology, combined with differential pressure principle, to finish this working progress. Taking the electric rotary feeder as the feeding device, the material is evenly put into the mixing chamber. At the same time of fluidization, the high-speed of airflow is produced by roots blower sends the material into acceleration chamber, and the suspension flow goes into the silo through conveying pipeline. After the filter is separated, the powder falls into the silo while gas release into the atmosphere. The powder conveying purpose is achieved.
