Scarab - Model M6 GVW 13 to 18 Tonne -Twin Engine Road Sweeper
The M6 is designed to incorporate all the essential features of a heavy duty roadsweeper capable of being mounted onto virtually any internationally available 13 to 18 tonne GVW truck chassis. Incorporating all the benefits associated with Scarab equipment, the rugged construction and a carefully selected range of options ensure the M6 delivers outstanding performance in municipal, urban or contracting work. The M6 can be supplied as a completely built machine from the factory or for specific markets can be supplied as an Export Skid Unit for local mounting in the country of destination. Whatever the application, wherever the location, the M6 street sweeper is a cost effective solution for the demanding owner.
The M6 street sweeper can be fitted to a wide range of chassis including those from DAF, Iveco, MAN, Mercedes, Volvo, Renault, Hino and UD. For details of these and other suitable chassis specifications, please contact our sales department.
Twin Drive
The M6 has been designed for operators who prefer a twin-engine configuration but who also wish to benefit from the very best in roadsweeper technology.
All the qualities that make Scarab the street sweeper of choice for so many operators are incorporated in the M6.
The simple fluid power system and Scarab’s industry leading CANbus control reduce ownership costs and maximise reliability.
Auxiliary Engine
The low-emission engine was selected for its ability to provide ample power at low revolutions. Its position, between hopper and water tank, reduces in-cab noise levels and also facilitates ease of servicing, with all engine filters and service points being accessible from the large working platform.
Hydraulic System
The Scarab fluid drive system is directly coupled to the auxiliary engine. By eliminating drive belts, gearboxes and flywheel couplings, it ensures quiet, efficient sweeping and suction performance and a high degree of reliability.
All the hydraulic control components are housed in a secure locker.
Scarab’s CANbus control system has revolutionised the way road sweepers are operated and maintained.
Intuitive controls and a conveniently positioned colour monitor provide comprehensive levels of feedback to both operating and service personnel.
A graphical display indicates the sweeping configuration and conditions of the vehicle systems including warnings and regular service reminders. Real-time monitoring and datalogging provides valuable assistance in resolving problems and achieving optimum machine performance.
Scarab CANbus includes universal connectors for fitment of Global positioning System (GPS) and the option of real-time data via telematic up-link.
A conveniently positioned colour monitor displays operating information in graphical form and enables the driver and service personnel to scroll through a number of screens to display and adjust vehicle set-up.
