Taziy - Model TZ -Screw Press Juicer Machine
The screw press juicer machine also named dewatering screw press, which is the common type of juicer machine used in many fields. This commercial juicer machine can be different types, such as the single-screw press, twin-screw juicer and the special type of juicer machine. This screw press can be widely used for making fruit juice, distiller’s grains and sawdust press dehydration, sewage and dewatering of sludge and kitchen waste.
What is the screw press juicer machine?
This machine can be used for solid-liquid separation processing of certain fibrous or viscous materials. For example, fermented grape skin residue, ginger, spinach, rubber, Chinese herbal medicine, winter jujube and other fruits and vegetables containing certain fiber can also be used for continuous juice extraction of sea buckthorn fruits except for branches or small branches. The machine’s mesh can be customized to the size of the material. This juice press machine can also be used in environmental protection industries, such as press and dewatering of market waste and kitchen waste.
How does the dewatering screw press work?
When the fruit juicer machine working, the material enters the crushing box through the inlet of the machine. Then the broken rod in the feed port quickly breaks the material by rotating at a high speed. The broken material is screwed into the press. The conveyor screw of the press will push the material entering the bin towards the pressing screw.
The pitch of the pressing screw is reduced and the shaft diameter is increased, and under the action of the screen wall and the resistance of the cone, the liquid (or juice) contained in the material is quickly extruded. The extruded liquid flows out of the sieve opening on the outside of the press and is concentrated in the juice hopper.
The pomace after pressing is discharged outside the machine through the end of the sieve cylinder and the cone. The rear of the cone of the machine is fitted with a spring. The pre-tightening force and position of the spring can be adjusted to change the discharge resistance and the size of the slag opening, thereby adjusting the dryness and wetness of the pressed fruit slags. The feeding box, sieve cylinder and spiral of the machine are made of high-quality acid and alkali resistant 304 stainless steel.
Classifications of the screw press dewatering machine
According to the different inner structures of the screw press, and their different applications for juicing and dewatering, the commercial screw press juicer machine can be divided into two types: the single-screw press, the twin-screw juicer and the special type of screw juicer.
Structure diagram of the screw juicer
Single-screw press juicer machine
The single screw press has a single-spiral structure inside. It is a pressing device with a spiral and a spindle rotating in the same direction. It is suitable for pressing materials containing fewer plant fibers and relatively smooth material surface, such as the pressing of vegetables and fruits such as grapes, berries, cabbage, melon, aloe, and the press of oil residue.
Single-screw continuous juicer machine applications:
- All kinds of Chinese medicine slag (sticky after fermentation is not suitable).
- A variety of vegetables and fruits, fresh grape skin residue and fermented grape skin residue, sea buckthorn fruit, pineapple and other juices containing certain fiber and vegetables, plant stems, roots, such as corn stover dehydration.
- Undigested garbage and domestic garbage in the vegetable market.
- Medical plastic waste and various Chinese medicine slag.
- 100% fiber pulp residue, sawdust, wood chips, crude (cotton) fiber black juice extraction.
