Zhuhai Wangyang - Model WY-SW-70 - 70TPD -Seawater Desalination Equipment for Aquaculture
The aquaculture seawater desalination equipment adopts the international advanced reverse osmosis technology and is designed by optimizing the system. It has the characteristics of small size, light weight, space saving, easy installation and strong adaptability. It is suitable for land and island. The equipment is simple to operate and easy to maintain. As long as the seawater and power are provided, the water can be produced after startup. The equipment has high desalination rate, stable performance, safety and reliability, and novel and clever design.
The system can effectively remove inorganic salts, heavy metal ions, organic bacteria, bacteria and other harmful components in seawater, and desalinate seawater into high-quality water in accordance with the National drinking Water Sanitation Standard (GB5749-2022).
When used in aquaculture, the equipment can quickly perform seawater concentration treatment to increase seawater salinity, and the concentration multiple is 2-10 times.
- Model: WY-SW-70
- Water yield: 2.91 m3 per hour
- RO product water quality: National Standard for Drinking Water(GB5749-2022)
- Concentrated water: suitable for aquaculture seawater standards
- Desalination rate: >99.5%
- Output water saltness: <700mg/L
- Recovery rate: 40%(Depending on temperature and inlet water quality)
- Operation pressure: <6.5Mpa
- Power: 20KW
- Voltage: AC380V / 50Hz / Three phase
- Protection grade: IP54
- Dimensions: 2600*1200*1900 mm
- Net weight: 600Kg
- Material composition: SUS316 Stainless steel
* 1. The amount of water produced refers to the amount of water produced under the conditions of an inlet water temperature of 25 ° C, a salt content of 35,000 mg/L, and an operating pressure of 5 MPa.
2. Equipment can be customized according to customer requirements.
- High-pressure unloading, when the high-pressure pump outlet pressure exceeds 6.2MPa, the equipment automatically stops and protects and emits an audible and visual alarm.
- Low-pressure shutdown protection. When the pre-treatment water supply is insufficient and the high-pressure pump inlet pressure is lower than 0.05MPa, the protection action will be automatically stopped and an audible and visual alarm will be issued.
- The pre-treatment is equipped with an manual multi-way valve for large-flow backwashing and full washing.
- Configure the reverse osmosis membrane cleaning system to physically clean, chemically clean and refill the reverse osmosis membrane module.
- Feed Pump: SUS316, CNP brand
- Disc Filter: UPVC
- Precision Filter: 40" x 5μm, FRP
- High Pressure Pump: SUS316L, Taiwan Diamond brand
- Reverse Osmosis Membrane: USA DOW/ TORAY/ HYDRANAUTICS brand
- Membrane Housing: 1000PSI, 3 Core, FRP, 2pcs
- Rinse Tank: 120L
- CIP Chemical Cleaning Device: System matching
- Conductivity Meter: Createc/ GF
- Electric Element: Schneider brand or equivalent
- High pressure pipeline: High pressure 2205 duplex steel
- Low pressure pipeline: PVC, SANKING brand
