GemmeCotti - Model HTM SP -Self-Priming Mag Drive Centrifugal Pumps
FromGemmeCotti Srl
HTM-SP pumps combine the typical features of our mag drive centrifugal pumps with the self-priming capability. At sea level these pumps can prime up to 6 meters. HTM-SP pumps are made of Polypropylene (PP) or PVDF, a thermoplastic material that ensures the best resistance to most chemicals. Thanks to the innovative sealless magnetic drive system, the pump model HTM-SP guarantees the maximum safety and efficiency, reducing the risks of leakage and emissions in the environment and the maintenance costs. The pumped liquid has to be clean, without solids in suspension.
Most popular related searches
mag drive centrifugal pump
centrifugal pumping
centrifugal pump
self-priming pump
industrial pump
corrosive liquid
sealless magnetic drive pump
centrifuge
self-priming centrifugal pump
magnetic drive pump
Anti-corrosion industrial pumps suitable for pumping acids and bases fluids and highly corrosive liquids
- Materials available: PP or PVDF;
- Materials in contact with the liquid:
Pump housing: PP or PVDF;
Impeller: PP or PVDF;
O-ring: EPDM (standard for PP pumps) / VITON (standard for PVDF pumps);
Static shaft: Al2O3 99.7%;
Bearing: PTFEC. - Capacity up to 25 m3/h.
- Head up to 22 m.
- Max temperature: PP: 70° C – PVDF: 90° C.
- Max viscosity: 20 cSt.
- Pressure rating: PN6 at 20° C.
- Self-priming up to 6m at sea level.
- Suction connection available in 3 welded configurations (frontal, on the right and on the left).
