Senba - Model ISB-TS45H -Infrared Thermopile Sensor
ISB-TS45H Infrared Thermopile Sensor can be widely used in non-contact temperature measurement. This product consists of infrared filters, thermistors and other components, and packaged by TO-46Made of metal, it has high reliability and high sensitivity.
Most popular related searches
non-contact temperature monitoring
contact temperature monitoring
infrared sensor
temperature monitoring
NTC thermistor
digital temperature controller
temperature monitoring system
thermometer
industrial thermometer
Output Sensitivity of Infrared Thermopile Sensor ISB-TS45H
Test conditions: under 25 °C, the measured object temperature vs the typical output voltage
of thermopile
* Note: This parameter is tested with TO-46 package and LWP 5.0 filter.
-
Non-contact temperature measurement
-
Ear thermometer, forehead thermometer
-
Industrial continuous temperature control
-
TO-46 package
-
High sensitivity
-
NTC thermistor compensation
-
Fast response
-
5μm Long-wave pass filter
