Senceive FlatMesh NanoMacro - Model PDS-FM3NT-50 -Triaxial Tilt Sensor Node

SHARE

The FlatMesh NanoMacro is an extremely high precision and exceptionally stable three axis tilt sensor which reports its measurements through Senceive’s FlatMesh wireless communications network to a FlatMesh Gateway. The FlatMesh NanoMacro is highly robust, has a long battery life, and comes with Near Field Communication (NFC) ™ capability, enabling on the spot interactions with the node.

Most popular related searches
triaxial sensor
temperature sensor
temperature sensor mounted
integrity monitoring
tunnelling
waterproofing
deformation measurement

Successfully applied in many applications, including those measuring:

  • Tunnel deformation
  • Tunnel heave/settlement
  • Embankment slippage
  • Structural movement
  • Rail track heave/settlement
  • Rail trackbed cant and twist

  • Integrated triaxial tilt sensor
  • Extremely low noise performance
  • Extremely low profile
  • Resolution of 0.0001° (0.0018 mm/m) and repeatability of ±0.0005° (±0.009 mm/m) (Standard version)
  • Operational in any orientation
  • Integrated battery
  • 12-15 year battery life, including when acting as a relay node within the mesh communications network
  • Integrated temperature sensor
  • Versatile mounting options
  • Waterproof to IP68 / IP69K
  • NFC capability, enabling on the spot adjustments to the node
  • “Sleep mode” functionality
