Separa - Model BIO-S -Sewage Treatment Plants
Mechanical-biological treatment of waste water - bottled, all-plastic, the type of BIO-S is a device for purifying waste water generated from small sources of pollution that can not be for its location, or otherwise connected to the central sewage treatment plant.
WTP series BIO-S is used for anaerobic treatment of waste water from residential sites, farms with a capacity of 2 to 10 EO (EO for 1 is considered the value of BOD5 60 g / day and the amount of waste water 150 l / d). WTP series BIO-S can be used for objects that are not permanently inhabited as recreational facilities. WTP can be combined with a natural sand filter treatment plant or root.
Like a basic data for the design and location are used requirements of investors of spatial planning and water management authorities.
The base consists of WTP plastic tank with three functional areas - sedimentation and insertion space anaerobic reactor. All parts of the plant are made of polypropylene integral. The tank is closed with a cover of polypropylene plates, resistant to UV radiation. The lid is fitted with inspection hatches.
Inlet for connection to the sewer is made PP pipes DN 160/140 mm, outlet pipes DN 110/90 mm. For correct function WWTP design for maximum flow and overall metabolic load. At maximum fabric and hydraulic load is the value of BOD5 in the effluent to 45 mg / l
