Shovoy - Model SHA308 -Amphibious Excavator
Shovoy SHA308 amphibious excavator is a light amphibious equipment among all our range. The machine comes with 0.2 cubic meter bucket with a standard reach of 9 meters. It is powered by Yannmar engine originally from Japan, with very good performance and fuel cost effective. The length of the pontoon of hydraulic undercarriage is 6.7 meters with high grade weathering steel material, the operating weight of the machine counts to 15 tons.
Main Features of SHA308 Amphibious Excavator;
Reliable Power Supply
The engine we are applying on amphibious excavator is Originally from Japanese maker Yanmar Motors Limited. It is a turbocharged 4-cylinder diesel engine with mechanical injection fuel pump. After years market test in West Africa, it is proved to be the best choice for amphibious equipment with give very little problem.
Top Grade Hydraulic Undercarriage
Chancos engineers use superior material and workmanship for undercarriage construction, weathering steel plate with high tensile strength and good corrosion resistant is used in the fabrication of pontoons. The weathering steel sheet we are using come with a 32.4% higher yield strength and 14.6% higher tensile strength over ASTM A242 or A606 type 4 steel ( used to be referred as Cor-Ten A and Cor-Ten B). It also has 6-8 times the atmospheric corrosion resistance and 6-10 times the paint adhension than Chinese Q345B steel sheet. The outline shape of Shovoy amphibious hydraulic undercarriage takes reference from ocean vessel, which enable the machine to move in swamp area or water with lower drag, resulting to more economic running cost as well as longer service life.
