Shovoy - Model SHD61 -Bulldozer

Engine
The C series engine contains the technologies of the imported engine of the CATERPILLAR 3306 of America. Key machining, inspecting and testing equipment for the engine were imported when the CATERPILLAR 3306 engine was being introduced. In 2006, SDEC upgraded the C series engine incorporation with FEV (Germany) to improve its power performance as well as fuel economy and to reduce its emissions. The upgraded C series engine has high power, low fuel consumption, and excellent reliability, carrying on the legend of KING OF POWER.

Gearbox
The gearbox is of the planetary gears type, by operating hydraulic control valve for traveling forward and backward. It features planetary gears, multi-disc clutch, hydraulically applied forced lubrication, 3 speeds forward and 3 speeds backwards.

Final Drive
For tip relieve and crowned gears which features large loading capacity, stable transmission and long lifetime.
