Sieman - Model M-100 -Automated Biosensor Analyzer

M-100 Automated biosensor analyzer available for the fast and accurate determination of

• Glucose
• Lactate
• Glutamate
• Lysine
• Ethanol
• Methanol
• Glutamine
• Glycerin
• Xylose
• Sucrose, etc.

*Different language versions are available It is especially suitable for the process that requires frequent detection of the corresponding substance concentration in the fermentation industry.  M-100 Automated biosensor analyzer is stable and cost-effective, and is the first choice for CHO cell culture process development.

This device is available for detecting the concentration of the test sample by use of the specially designed bio-oxidase membrane electrochemical sensor.

M-100 Automated biosensor analyzer could automatically collect samples and import them into the test area. The test substance contained in the sample will undergo an enzymatic hydrolysis reaction under the catalysis of an immobilized bio-oxidase to generate hydrogen peroxide. The concentration of the test substance is calculated by the hydrogen peroxide concentration that is generated in the detection of hydrogen peroxide electrode.

The device can calibrate a standard item with a known concentration, and the voltage value of the standard item is a measure of the concentration of the test substance. The unknown concentration can be obtained through the comparison with the voltage signal of the standard item. The sensor electrodes will be automatically cleaned by the system buffer solution after each measurement is completed, and the next test can be performed after cleaning.

• Faster detection speed, reaction time only 20 seconds;
• Independent research and development of immobilized enzyme membrane technology, longer life, lower detection cost;
• Automatic sampling, automatic calibration, reduce human error;
• Electrochemical detection principle, strong anti-interference ability, not by fermentation liquid background color interference;
• Multi-function menu, man-machine interactive operation, multi-user login to meet authentication requirements;
• Supports 3Q authentication;
• You can set the automatic repeated detection times to provide more reliable detection data;
• Test data, calibration data is exported by one key;
• 15 samples can be processed at one time to meet the requirements of experimental design in process optimization stage.
