Sigma - Gasketed Plate Heat Exchange
Plate heat exchangers use corrugated plates stacked between a fixed and movable pressure plate. As virtually all of the material is used for heat transfer, plate heat exchangers can have large amounts of effective heat transfer surface in a small footprint. It is not uncommon that a plate heat exchanger will have the same thermal capacity as a shell and tube five times larger. Our plate heat exchangers incorporate superior design features to ensure long-term performance and customer satisfaction.
Most popular related searches
heat exchanger plate
fluid leak detection system
fluid leak detection
gaskets
process fluid
fluid leak
current flow
industrial HVAC
leak detection
HVAC industry
PERFORMANCE NOTES
- Unique corrugation pattern pressed onto each plate produces the highest overall heat transfer rate by assuring turbulent flow and excellent fluid distribution across the entire surface
- True counter current flow and high heat transfer rate allows our plate heat exchangers to economically handle close temperature approach requirements
- Highest quality gaskets precisely fit the plate grooves for positive sealing and ease of maintenance
- Superior clip-on gasket design ensures proper fit during closing of the unit
- Double sealing design prevents the possibility of mixing the two process fluids; leak detect feature ensures any leakage is to the atmosphere
- Zinc coated hardware provides long life
- All bolted construction for easier service
- Low volumetric fluid hold-up provides quicker response to heating and cooling demands, while reducing costs for more expensive process fluids
- Readily expanded for greater capacities, or totally new applications
- Available in a variety of plate sizes for industrial, HVAC, power, or food industry applications
OPERATING PARAMETERS
- Temperature: -29°C – 200°C
- Pressure: Vacuum to 30bar
- Capacities: In excess of 4,500 m³/h
- Connections: Up to DN500
TECHNICAL PARAMETERS
- Plates:
- Standard: AISI 304 stainless steel (1.4301), AISI 316L stainless steel (1.4404), AISI 316TI stainless steel (1.4571)
- Exotics: AISI 904 stainless steel, SMO 254, Nickel alloys, pure nickel, Ti and Ti-Pd alloy
- Thickness: 0.4 mm to 1.15 mm
- Gaskets:
- Standard: Nitrile rubber gasket, EPDM rubber, chloroprene rubber
- Exotics: HNBR, NBR-HT, FPM/FKM, butyl, PTFE coated (SIGMACOAT), food industry certified gasket, AFM hard gaskets, others available
- Attachment Method: SIGMAFIX adhesive-free gasket, or glued gasket
- Frame: Painted carbon steel, or stainless steel (solid and clad)
- Connections:
- Standard: Studded with option for liner, flanges (ANSI, DIN), food stuff connections
- Exotics: Ti, SMO, hastelloy, and 904L, others available
- Codes and Standards: PED, ASME, ABS, LRS, GL, BV
