Oliver - Model B6F -Single Isolating Ball Valve
Our compact style Double Block & Bleed Valve is designed with an overall length in accordance with ASME B16:10. The single piece body design reduces potential leak paths and allows weight and space to be kept to a minimum. Available with either trunnion mounted ball or floating ball design and with both full and reduced bore sizes.
Our High Pressure Ball Valves are offered in three different configurations, namely: Integral Compression Ends, Threaded Ends Female x Female and Threaded Ends Male x Female.
As with our low pressure ball valves, our High Pressure Ball Valves offer totally enclosed soft seating, which gives the valve a positive sealing, and low operating torques across the whole pressure range. Unlike our low pressure ball valves, our High Pressure Ball Valves are capable of withstanding PSI ratings up to 10,000 PSI, and are recommended for use in the Oil, Gas and Petrochemical industries.
With a one-piece spindle with anti-blow shoulder, our High Pressure Ball Valves maintain seal integrity throughout the pressure ranges. We are also able to work with customers to provide High Pressure Ball Valves with increased body integrity through either PTFE or Graphite Foil spindle and body seals.
The handle found on our High Pressure Ball Valves is manufactured using 316 stainless steel, fitting with twin anti-vibration locknuts.
- PSI Rating 6,000 PSI
- Temperature 120 Deg C
- Seals PTFE
- Thread Form NPT (AS STANDARD) / BSPP / BSPT other on request
- Connection Size From 1/4" to 1"
- Handle Lever
- Seats PTFE/PVDF
- Bore 10mm / 14mm / 20mm
