Yosemitech Technologies Co., Ltd.

YosemiteModel Y610-B -Single-Parameter Universal Online Controller

SHARE

The universal online controller Y610-B is a versatile industry instrument that can automatically recognize `s digital sensors including optical dissolved oxygen, turbidity, COD, pH, Conductivity, Sludge, Chlorophyll, NH4_N, ORP, Salinity, BGA and OIW sensors. It provides a easy and reliable platform for in-situ water quality measurements. The controller Y610-B displays sensor measurements and other data, also can transmit 4-20mA signals. Outputs and sensors can be easily configured and calibrated through the user interface. The online controller can be used in biological, chemical process control, waste-water process monitoring and other in-situ water quality control and monitoring applications.

Most popular related searches

Model: Y610-B

  • Size: 144*144*115 mm
  • Display: 77*53 mm
  • Weight: 0.8kg
  • Working Temperature: 0~55℃
  • IP Rating: ABS,IP65
  • Humidity: ≤80%
  • Power: 110~220V AC
  • Output: A 4-20mA, a RS-485 , two Relay opt coupler
  • Pressure Compensation: Built-in,auto compensation in 50~115kPa
  • Sensor Type: Support Yosemitech’s digital sensors including DO, COD, turbidity, pH , BGA Sludge, Conductivity, Chlorophyll, NH4_N, ORP, Salinity and OIW sensors
  • Installation: Wall or panel mounting(Hole size:138*138mm)
