Yosemite - Model Y610-B -Single-Parameter Universal Online Controller
The universal online controller Y610-B is a versatile industry instrument that can automatically recognize `s digital sensors including optical dissolved oxygen, turbidity, COD, pH, Conductivity, Sludge, Chlorophyll, NH4_N, ORP, Salinity, BGA and OIW sensors. It provides a easy and reliable platform for in-situ water quality measurements. The controller Y610-B displays sensor measurements and other data, also can transmit 4-20mA signals. Outputs and sensors can be easily configured and calibrated through the user interface. The online controller can be used in biological, chemical process control, waste-water process monitoring and other in-situ water quality control and monitoring applications.
Most popular related searches
water quality control
chemical process control
water process monitoring
water quality monitoring
water quality
process water monitoring
industrial instrument
water control
process monitoring
process waste
Model: Y610-B
- Size: 144*144*115 mm
- Display: 77*53 mm
- Weight: 0.8kg
- Working Temperature: 0~55℃
- IP Rating: ABS,IP65
- Humidity: ≤80%
- Power: 110~220V AC
- Output: A 4-20mA, a RS-485 , two Relay opt coupler
- Pressure Compensation: Built-in,auto compensation in 50~115kPa
- Sensor Type: Support Yosemitech’s digital sensors including DO, COD, turbidity, pH , BGA Sludge, Conductivity, Chlorophyll, NH4_N, ORP, Salinity and OIW sensors
- Installation: Wall or panel mounting(Hole size:138*138mm)
