Oldcastle Infrastructure, Inc.
Single-Phase Sectionalizing Cabinets
Our versatile fiberglass single-phase sectionalizing cabinets can be pad-mounted or buried. The cabinet’s hinge-less lid rotates beyond 90 degrees and stays open for overhead equipment operations. These durable primary cabinets are offered in several sizes.
Most popular related searches
Features and Benefits
- Direct Burial or Pad-mounted on concrete pad.
- Complete access from top and sides when lid is open.
- Rugged fiberglass construction.
- Smooth aesthetically pleasing exterior finish.
- Weather and UV enhancing outer coating applied.
- Standard color Munsell Green, other colors may be available upon request.
- External hardware is stainless steel or brass.
- No hinges, cover rolls back on (2) pivot points.
- External step design for greater side wall support.
- RUS Accepted.
- Junction mounting boards are easily removable for installation of load-break junctions.
- Will accommodate 15kV and 25kV, 200Amp and 600Amp junctions. Factory installed junctions can be provided.
- Wind lock provided for added safety.
- Optional removable front panel on FSC3353R unit for complete access.
- Below line parking stands are standard. Inline or adjustable above line parking stands available.
