Gross - Model Series GAZ 82, GAZ 82 S -Single Shaft Grinder
The slow turning single shaft grinders GAZ 82 and GAZ 82 S are specially built to meet the demands of the woodworking industry. It can shred all types of wood waste such as chippings, pallets, particle board etc. The basic models are equipped to customer specific requirements (throughput capacities, hopper and rotor design etc.).
- Powerful drives, with optional hydraulic clutch, 5 fan belts, robust gearbox, gear limit
- Various screens
- Turbo hydraulic with optional oil cooling
- Rotor with one row of knives for low power consumption
- Rotor with a diameter of 368 mm with two rows of knives for higher throughput
- Segmented floor
Material is fed through the hopper in front of a hydraulically operated pusher which pushes the material under load-dependant control onto the revolving rotor. The material is shredded between the rotor knives and a fixed counterknife. The pusher is fitted with wiper strips which prevent material from entering between the drawer and machine housing. The perforated sieve with varying hole diameters determines the size of the chippings or shavings. The shavings produced can be removed from the machine by means of a suction device or a screw conveyor. As soon as the material in the hopper has been completely shredded, the machine switches off automatically.
