Forrec - Model MR 1500 -Single Shaft Shredders Potentiated
FromFOR REC S.P.A.
The MR series single shaft shredders have expressly and especially designed for application in tyres processing and for materials with high specific weights. In these kinds of application the mechanical parts are subject to particular stressing for this reason the machines have been projected with an oil bath transmission with gearbox without ram to reduce overloads and vibrations.
Most popular related searches
- High number of rotations (120 rpm)
- Single shaft with parallel axis engine reducer
- Configurable automatic gear reversal
- Bearings outside of the cutting chamber
- Automatic greasing managed by PLC
- Use of high quality steels
- Epicyclic reducer MR1500 / Absence of reducers MR2000
- Oil bath chain transmission
- Configurable blades for thickness and number of teeth
Overall Dimensions::
3700 x 2500 mm H=4800 mm
Blades:
interchangeable plates
Rotor dimensions:
L1500 – Ø 700 mm
Plates dimensions:
48 x 48 x 30 mm
Weight:
16000 Kg
No. of plates:
84
Motor drive:
200 kW
- Tyres
- Material with specific high weight
