SmartWatchWeb - Model SWWRF41 -Wireless Field Device
FromBitherm
Bitherm SmartWatchWeb SWWRF41 is a wireless device for steam and gas leak detection on steam traps and valves. SWWRF41 is powered by lithium thionyl chloride battery. Its design is optimized for low power operation, improving lifetime of battery-powered devices. High output power (up to 20 dBm) allows to improve link quality and maximum distance between nodes even in industrial environments. SWWRF41 is small size to easy installation on small steam traps.
Most popular related searches
gas leak detection system
gas leak detection
gas leak
leak detection
steam control valve
steam leak detection
steam leak detection system
gas detection
ATEX certification
monitoring network
Bitherm’s SmartWatchWebTM system can be used to detect and survey steam leaks and gas leakages on any Relief & Safety valve, steam traps or similar. Among the typical applications for this product we can list:
- Improving energy efficiency
- Reducing deployment costs
- Autonomous monitoring nodes
- Network support for other Bitherm products
- 2.4 GHz ISM Band RF link:
- ISA 100.11A
- 802.15.4 standard compliant
- Half-Duplex communication
- ATEX / IECEX Certificated (pending)
- Low Power:
- < 100 μA sleeping mode
- down to 500 μA equivalent continuous
- consumption in active mode (configuration dependent)
- IP66 Protection Grade
