SMC - GRP Water Tank

• Tank Panel
• Reinforcenent
• Partition
• Assembly

ldeal of strong for clean Drinking Water.

GRP Sectional Panel Tanks are constructed of panels made from SMC (Sheet Molding Compound) by hydraulic hot press under high temperature (150?) and pressure conditions to maintain the best endurance.

Using stainless steel for the interior structure and plated steel for the exterior, the panel Exhibits excellent resistance to erosion.

Easy insllation with on-site bolt assembly and Tank shape and volume can be freely Designed with no restrictions based on site location, weather or climate.

Super Hygienic
Hygienic SMC Panel

It is possible to make the GRP panels in a variety of colours. In most cases, however, this Type of tank is installed in the open, exposed to direct sunlight. If the GRP panels are Transparent, the growth of algae and other
micro-organisms would be accelerated.

SMC has adopted panel to minimize this problem, completely opaque and does not permit the passage of any light through it.

A typical problem with steel tanks has always been the high thermal conductivity and expansion of coefficient of steel. These characteristics can cause loosening of the panel connecting bolts in areas of wide temperature change.

Sizes adaptable to any needs
From small tanks to large, SMC panel can fit virtually any order. Tank sizes are selectable to fit each need and desire, SMC tank can be installed to Handle from 0.25(?) up to NO LIMIT !

Various sized panels can make the below tanks that utilize the most horizontal & perpendicular space and also can be used as home use small tanks & Big ones.

The water pressure created by filling the tank seals the joints preventing leakage In other type tanks, water pressure can open the joints breaking the seal, and allowing the stored

Hydrostatic Test

• In accordance with SS245:1995 Specification for Glass Reinforced Polyester Sectional Water Tank.
• Test Pressure : GHP × 6 = 2.4bar (9.81 × 4 × 1,000 ×) / 10.6

The heat insulation panel with 3 layer structure Improve heat insulation effect, protects water condensation on the outside of the tank and minimizes  temperature variation of the stored water.

The joints are sealed with a special sealing tape especially developed for SMC TANK with long experience and technology on SMC products.  It maintains soft itself and adhesives even at low temperature.  The combined flange thickness at the panel joints is sufficient to meet any stress imposed. This self sealing feature eliminates the possibility of separation and hence prevents leakage of the tank.

The convex bottom panels with can cave draind panel system make sure complete and fast drainage. It’s very useful to take a maintenance inside of water tank.
