Snyli - Model H13-U16 -PTFE HEPA Filter
PTFE HEPA filter/ ULPA filter that is polytetrafluoroethylene High-efficiency/ ultra-high-efficiency filter. H13-U16 is available. Compared with glass fiber filter and PP filter media,PTFE HEPA filter/ ULPA filter media has great advantages, such as extremely low chemical gas dispersion, better uniform fiber distribution, smaller fiber diameter and pore size. These features can greatly reduce filtration resistance and improve filtration performance, thereby greatly reducing energy consumption.
Most popular related searches
HEPA filter
ULPA filter
glass fiber filter
polypropylene filter media
HEPA
glass fiber filter media
fiber filter
polypropylene filter
media filter
chemical dispersion
- Frame: Aluminium alloy / Galvanized steel/Stainless steel
- Media: Polytetrafluoroethylene (PTFE)
- Media guard: Paint finished expanded mesh
- Standard Frame thickness: 55mm, 70mm (Non standard thickness can be customized)
- Design: Panel type
- Maximum temperature: 250ºC
- Maximum relative humidity: 100%
- Filtration efficiency:
- HEPA
- MPPS:≥99.95%(H13) DOP:≥99.99%@0.3um
- MPPS:≥99.995%(H14) DOP:≥99.999%@0.3um
- ULPA
- MPPS:≥99.9995%(U16) DOP:≥99.9995%@0.12um
- MPPS:≥99.99995%(H14) DOP:≥99.99995%@0.12um
- High toughness, strong damage resistance, in harsh environments, with excellent acid resistance (including Fluoric acid), alkali resistance, resistance to organic substances.
- Low volatility (boron-free) clean material, reducing the release of impurity waste gas (boron, potassium, silicon, etc.); no metal pollutants.
- Compared with ordinary glass fiber materials, the pressure loss is reduced by about 40%, which reduces energy consumption, saves space and reduces weight.
- Lightweight, good sealing, compact structure, easy installation, high efficiency, low resistance and low operating cost.
PTFE HEPA filter/ ULPA filter is widely used in semiconductor, electronics, precision manufacturing, bio-pharmaceutical and other industries.
