Sonic - Model Probe 200 -Track Drill Rigs
Steel deck complete with nonskid walking surfaces. Hydraulic stabilizer legs (two). 80 gallon hydraulic oil tank (approximately). Safety decals (English). Fully painted, black and white. Rexroth valves, pumps and controls (where possible). Control console, swing mounted. Safety and operation manual (two copies, English). Three hole pump drive box (Funk) complete with clutch. Approximately 14 gallons hydraulic oil (AW46) 56 HP diesel powered unit (Perkins 404D - 22T 2.2 litre turbocharges, EC Stage 3A/USA EPA Tier 3) complete with enclosure. EP-26 drill head.
Most popular related searches
drilling rig
electric valve
water pump
drilling rod
EPA 3
pump controller
sonic drilling rig
ultrasonic processor
decontamination
water modeling
- Accessory power port, 12V
- Breakout table, tower mounted (2 in (51 mm) to 6 in (152 mm) nominal, 2 level)
- Breakout table, tower mounted (2 in (51 mm) to 6 in (152 mm) nominal, 3 level)
- Custom colour (non-metallic)
- Decontamination racks
- Extended mast (increases tower maximum drill rod length to 6-1/2 ft (2 m)
- Horizontal tower positioner (4 way)
- Hydraulic oil type (non standard)
- Jib hoist complete with 1,100 lb (500 kg) winch (164 FPM (50mPM) max)
- Lighting package
- Operator training and on site assistance
- Machine vise and mount
- Receiver hitch hookup
- Pipe guides (includes 1 standard size insert)
- Stationary rod rack (for 5 ft (1.5m) rods)
- One auxiliary hydraulic service line with electrical, valve and hydraulic quick disconnect
- Water pump, FMC Model E0413 HD (20 GPM (76 LPM)/600 PSI (41 BAR))
- Water transport system
