KURZ - Special Silos

These can be:

• Silos according to ATEX guidelines
• Flat-bottom silos
• Sewage tanks
• Bitumen tanks
• Bulk material bunkers
• etc.

PRESSURE-SHOCK RESISTANT SILOS

• Storage of bulk materials which may form explosive dusts
• Static design of the silos
• Design to ATEX guidelines
• Determination of pressure relief surfaces
• Fitting with explosion doors or bursting discs
• Design for reduced explosion pressures
• Complete fitting with measurement and monitoring equipment
• Inerting
• CO monitoring

FLAT BOTTOM SILOS

• Storage of heavy flowing bulk materials
• Mass flow silo
• Discharge by means of screw conveyor or sliding frame
• Ideal for storage of sewage sludge, wood chips and pellets

BUNKERS

• Bunker are usually used as receiving stations for all types of bulk materials
• Design in various shapes, e.g. rectangular, square, square to round
• Pneumatic and/or mechanical discharge equipment
• Covered with grating and/or closed with cover

BUFFER RESERVOIRS

• Buffer reservoirs for the buffering of bulk materials are frequently used for metering equipment.
• Individually designed sizes
• Reservoir can be weighed easily.
• Filling can be with KURZ volumetric metering equipment.
• Fitted with overflow protection and filter

LIQUID SILOS

• Storage of liquids
• High-quality internal coatings
• Stirrers
• Overflow channels
• Piping, e.g. inlet, overflow and return

BITUMEN TANKS

• Storage of liquid bitumen
• Tank insulation up to 300 mm thick
• Prepared for heaters
• Tank piping
