Spider - Float Switch
FromTecnoplastic Srl
The rods attached to the body allow the level regulator to work in narrow spaces and in difficult environments with turbulent waters.
Most popular related searches
float switch
industrial water container
industrial water
water industry
rainwater
electrical conductivity
water containment
water data
chemical containment
industrial containment
- CLEAN WATER
- RAIN WATER
- INDUSTRIAL WATER
- WATER CONTAINING CHEMICAL SUBSTANCES
Based on the electrical conductivity of the water
- Spider is connected to 3 batons: Common as ground - Min as minimuml level - Max as maximul level
- The water reaches the weel and the level increases
- Spider turns ON the pump when the maximum level baton detects the water
- The water level decreases and Spider turns OFF the pump when the minimum level baton doesn’t detect the water anymore
- Casing: Polypropylene
- Grommet: TPV
- Batons: AISI 316-> 250/500/750mm
