Stacking And Forming Machine
The equipment mainly realizes the production of one or two single-sided coating stack and separator forming on the surface of a consumer lithium-ion battery, and the special-shaped area of the separator is cut as a whole. Loading and unloading of layered stack, automatic cell loading and unloading, single-sided coating stack Stacking, hot pressing, laser cutting, cell stacking accuracy detection, bad product screening function, and compatible with regular shape and special-shaped battery assembly and other functions.50~3000 gf ± 10% tension setting range to ensure constant tension control turn by turn during unwinding;
≤10 min platen surface temperature rise time (RT to 100 ℃), high equipment efficiency;
The surface temperature of the platen can be set arbitrarily within 25℃～120℃, and the temperature control accuracy of the upper and lower platens is ±5℃;
The temperature uniformity of the platen is high, and the temperature difference of each point within the 150*150mm area of the pressure center is ≤5℃;
CCD has high detection accuracy and resolution ≤0.025mm, ensuring high alignment of stack and separator Stacking;
The front stack and the cell are dedusted to ensure that the requirements of Hi-pot detection in the rear section are met;
The dust removal design of the whole machine ensures that the production environment is clean and tidy;
Yield: ≥ 98%
Utiltzation: ≥ 95%
A/C Overhang: ± 0.3
A/S Overhang: ± 0.6
Temperature control accuracy: ≤ ± 5 ℃
Temperature uniformity: ≤ 5 ℃
Equipment noise: ≤ 75 dB @ 1 m
Total equipment power: 25 kW
Power Requirements: 380 V /50 Hz
