Skim-pak - Model 18500 Series -Stainless Steel Flow - Control and Floating Fixed Weir Surface Skimmer Systems
The skim-pak series 18500 skimmers are high volume, wave tolerant skimmers for use in tanks, ponds, harbors, wastewater clarifiers and with vacuum trucks. For complete clean-up and recovery systems, skim-pak skimmers can be combined with tested accessories.
skim-pak series 18500 is also designed for operations such as:
- Storage tanks
- Equalization tanks
- Settling Ponds
- Oil/Water Separators
- Waste Water Intake, Treatment and Discharge
- Lift Stations
- Oil and other VOC Spill Recovery
- Surface Water Pollution Control and Remediation
- Leachate Ponds
- Compatible with Vacuum Trucks
- Hoses - 1.5” PVC or high temp hose with cam lock quick disconnects
- Hose Floats - Vinyl or Stainless Steel
- Debris Screen - PVC Coated Aluminum or Stainless Steel
The skimmer is designed to remove floating product only, no underlying liquids. Oil accumulations, of any quality, are continually removed with no reoccurring costs and virtually no maintenance. The skim-pak system will continually remove accumulation above a predetermined cap of oil and it will never recover underlying water.
Model 18700 - SH
- Dimensions: 43” x 23” x 14”
- Weight: 78 lbs.
- Draft: 12”
- Material: 304 Stainless
- Hose Size: 3”/7.62cm
- Temperature Limit: 600°F/315°C
- Capacity: 300 GPM
The 18500 - SH is equipped with self adjusting flow control, the skimmer needs no adjustment for maximum recovery efficiencies. The result is a more efficient skimming operation at lower overall costs.
Model 18500 - SH
- Dimensions: 43” x 30.5” x 13”
- Weight: 57 lbs.
- Draft: 8”
- Material: 304 Stainless
- Hose Size: 3”/7.62cm
- Temperature Limit: 600°F/315°C
- Capacity: 10 - 300 GPM
