Onyx Valve - Model Series DHC -Stainless Steel Full Round Port Dual Pinch Valve
Full Round Port. Dual Pinch Mechanism. Stainless Steel Internal Parts. Can be Automated. Available with Limit Switches. Clog resistant full round opening.. Low pressure drop. No packing. Drop tight closure. On/Off or throttling service. Self cleaning ACME threaded stainless steel stem for easy operation.
Most popular related searches
- Flanges: ANSI STD 125/150 lbs.
- Housing: Cast Iron, ASTM A48, Class 35 ( Valve Sizes Up to 10′) Ductile Iron, ASTM A536-80, Class 65-45-12 ( Valve Sizes 12′ & Up )
- Stem: 303 Stainless Steel
- Guide Rods: 303 Stainless Steel
- Pinch Bars: Ductile Iron, ASTM A536-80, Class 65-45-12
- Bearing: Bronze Alloy
- Sleeve Elastomer
- Epoxy Paint
- ANSI STD 300 lbs Flange
- 316 Stainless Steel Stem
- Ductile Iron Housing
- Stem Cover Assembly
- Secondary Containment Package
- Limit Switches
- Chain Wheel
- Bevel Gear Box
- Machine/Ball Screw Jack
