LG -Â Model 304H -Stainless Steel Pipe
A 304H grade is a high-carbon austenitic stainless steel grade. The 304H Stainless Steel Pipe is designed with a superior chemical composition of 18% chromium and 8% nickel. The superior content gives these pipes enhanced corrosion and oxidation resistance properties. A Stainless Steel 304H Pipe performs well in elevated temperatures due to the presence of excess carbon embedded in it. These pipes also can withstand environments that contain reducing chlorides and sulfuric acids. They are; however, prone to pitting in marine systems. Welding the 1.4948 stainless steel pipe is slightly harder than the 304 and 304l grades. The pipes in this grade have a minimum tensile strength of 515mpa with a yield strength of 205mpa. The 304H Stainless Steel Tube can be easily elongated by a minimum of 40% while showcasing a hardness of Brinell 201 HB max. These tubes have a density of 8.0 g/cm3 with an elastic modulus of 193Gpa.
The 304h seamless pipe is a high-strength pipe grade designed with excellent load-bearing capacity. These pipes are produced by passing hot steel billets through the extruded metal followed by shaping it in correct dimensions. The versatile pipes are expensive due to the material used in their production but are worth it due to their excellent features. ASTM A312 Gr TP 304H is a grade designed for use in non-pressurized vessels or systems. The grade covers structural qualities and shapes for different piping grades. SA 312 TP 304H, on the contrary, covers pressurized vessel grades that are used in boiler and pressure vessel equipments. The items within this grade cover different codes and follow norms set by ASTM specifications. The 304H stainless steel grade is a complex pipe grade to manufacture and requires the best operators to produce the best pipes. We bolster an illustrious calvary of people who produce the best products at affordable rates compared to our overseas and local competitors.
- GRADES: TP 304L Stainless Steel Pipes / UNS S30409 / DIN 1.4301
- SIZE: 1/2" NB to 24" NB
- STANDARDS: ASTM A249 - A269 - A312 - A358 - A409 - A554 - A778 - A789 - A790
- TYPE: Seamless, Welded, EFW, ERW, Fabricated
- Marking:
- Supplier / Manufacturer’s Name or Custom Logo - on request
- Pipes Schedule or Wall Thickness
- Heat Number
- Specification
- Nominal Pipes Sizes
- Grade
- Manufacturing Method (Welded / Seamless)
- FORM: Round Pipes, Square Pipes, Rectangular Pipes, Oval Pipes, Hydraulic Pipes, etc.
- END: Plain End, Treaded, Beveled End
- TOLERANCE on Length: Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm
- FINISH: Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm, Polished Grit 120 - 600, Mirror Polished
