Rising - Model 304 -Stainless Steel Pipe
A stainless 304 grade steel is an austenitic grade that can be severely deep drawn. The Stainless Steel 304 Pipe is a common grade that is produced with a chemical content of chromium, nickel, and other constituting alloys. These pipes work well in temperatures above 800 degrees F and possess good corrosion resistance properties. A SS 304 Pipe works well in organic and inorganic chemicals in oxidizing environments. These pipes are tolerant to intergranular corrosion and can be readily welded in place.
The ASTM A312 Grade TP 304 Round Pipe possesses enhanced mechanical properties. These round bars have a tensile strength between 520 to 720mpa and possess minimum proof stress of 210mpa. They can be easily elongated by 45 in the system. A 304 SS Schedule 40 Pipe is a common schedule the pipes of these grades are available. These pipes have a density of 8 gm/cm3 and possess a melting point of 1450 degrees C. The Stainless Steel 304 Sch 40 Pipe has good machinability and is common in chemical, petrochemical tanks, heat exchangers, flanges fitting, valves, pumps, etc. The pressurized vessel ASME SA 312 TP304 SS Exhaust Pipe can be availed in a wide range of sizes that meet the requirements of different industries. The 304 Stainless Steel Pipe Manufacturers In India provide cheap products than in other countries due to the vast availability of raw materials and cheap labor.
SS 304 Seamless Pipe vs Welded Pipe?
A Stainless Steel 304 Pipe Supplier generally supplies piping products that are produced in either seamless or welded configurations. Both these types can be distinguished in certain aspects.
- The Seamless pipe is a single piece that is produced via an extrusion process. A welded pipe is produced as metal is rolled and welded using standard procedures.
- A Stainless Steel 304 Seamless Pipe has 20% higher load-bearing capacity and strength when compared to a welded pipe.
- The SS 304 ERW Pipes have a consistent wall thickness when compared to the inconsistent thickness of the seamless counterpart.
- The SS 304 Stainless Steel Welded Pipe is cheaper and comparatively easy to produce than a seamless grade pipe.
- The 304 Stainless Steel Pipe Suppliers can only supply seamless pipes up to 24 inches or less. The welded pipes have no restriction on the production size.
- ASME/ ASTM Name: ASME SA 358/ ASTM A 358 and ASME SA 312/ ASTM A 312
- Dimensions Standards: API,ASTM, ASME
- SS 304 Seamless Pipes Size Range: 1/2 inches Nominal Bore To 16 inches Nominal Bore
- outer dia Sizes: 1/8 - 30 inches Nominal Bore Inch
- efw pipes outer dia: 6 Nominal Bore To 100 inches Nominal Bore
- Available Pipes Forms: Hydraulic and Round Form Etc
- size range of erw pipes : 1/2 To 24 inch Nominal Bore
- SS 304 Seamless Pipes End Finishing: Plain End, Theaded, Beveled End
- Frequently Used Types: Welded / ERW /LSAW/ Fabricated /Seamless Pipes
- Pipes Schedule Thickness Range: SCH40, SCH20, SCH30, STD, XS, SCH80, XXS, SCH60, SCH80, SCH160, SCH140, SCH120,
- Stock Length of Stainless Steel 304 Pipes : Cut Length, single and double Random
