Luofu - Model Y12X-16P -Stainless Steel Wire Port Pressure Reducing Valve
Through the throttling of the opening and closing parts, the threaded pressure reducing valve Y12X/F causes pressure loss to force the inlet pressure to reduce a certain required value at the outlet. When the flow and pressure change, the purpose of using its own medium energy to control the outlet pressure is basically unchanged. .
Most popular related searches
Main technical specifications
- Nominal pressure: 1.6MPa
- Working medium: water, gas
- Working temperature: t≤80?
- High inlet pressure: 1.6MPa
- Adjustable range of outlet pressure: 0.15MPa-0.50MPa (the pressure set at the factory is 0.3MPa)
- Pipe thread complies with ISO228 standard
- Before installing this valve, carefully check whether the usage is consistent with the label.
- The threaded pressure reducing valve can be installed horizontally or vertically, and the arrow shown on the valve body must be consistent with the flow direction of the medium.
- This valve is only used for decompression in the pipeline, not for cut-off. The medium used must be filtered by a filter.
Spring pressure reducing valve model:
- Cast steel: Y12X-16C, Y12X-25C, Y12X-40C, Y12X-64C
- Stainless steel: Y12F-16P, Y12F-25P, Y12F-40P, Y12F-64P
