Geonica - Model XStream-PKG RF -Stand-Alone Radio Modems
XStream-PKG RF modems can be configured in minutes to provide low-cost serial cable replacement between all types of electronic devices. Available in 900 MHz and 2.4 GHz models, XStream-PKG modems provide transmission ranges of up to 20 miles in a low-cost wireless solution. The modems are coupled with a DIP-switchable RS-232/422/485 interface board and regularly outperform more expensive RF modems. Innovations stamped in their design enable XStream-PKG modems to yield two- to eight-times the range of competing modems. This allows OEMs and integrators to covermore ground with fewer devices.
Additionally, XStream-PKG modems are easy to use, thereby reducing the complexity of data system development. Available in a variety of data interface options, including RS-232/422/485 serial, USB and telephone, XStream-PKG modems can wirelessly connect a variety of devices across many applications including remote monitoring, building automation/security, industrial automation/SCADA, fleet management/asset tracking and sensor data capture in embedded systems.
Specially recommended for operation with the Remote Data Acquisition and Transmission Units METEODATA / HYDRODATA-2000C/3000C Series; as well as with the Remote Terminal Units (RTU`s) TAURO-2000/3000 Series from GEONICA.
- Indoor/urban range up to 1500 feet
- Outdoor line-of-sight range up to 32 km (with high gain antenna)
- 7 frequency hopping channels, each with 65K available addresses
- Outstanding receiver sensitivity (-110 dB @9600 bps)
- Low power consumption for power-sensitive applications - Pin, serial port and cyclic sleepmodes available
- Performs retries and acknowledgments for reliable packet delivery
- Easy out-of-the-box operation — no configuration necessary
- Durable industrial grade enclosure
PERFORMANCE
- Indoor/Urban range (w/ 2.1 dB dipole antenna):
- Up to 1500 feet (450 m) @ 900 MHz
- Up to 600 feet (180 m) @ 2.4 GHz
- Outdoor RF line-of-sight range (w/ 2.1 dB dipole antenna):
- Up to 7 mi (11 km) @ 900 MHz
- Up to 3 mi (5 km) @ 2.4 GHz
- Outdoor RF line-of-sight range (w/ high gain antenna):
- Up to 20 mi (32 km) @ 900 MHz
- Up to 10 mi (16 km) @ 2.4 GHz
- Transmit power output:
- 100 mW (20 dBm) @ 900 MHz
- 50mW(17dBm)@2.4GHz
- Receiver sensitivity:
- 900MHz: -110 dBm (@9,600 bps throughput data rate), -107 dBm (@19,200 bps)
- 2.4 GHz: -105 dBm (@9,600 bps throughput data rate), -102 dBm (@19,200 bps)
- Interface data rate (software selectable): 10 - 57600 bps (including non-standard baud rates)
- Throughput data rate: 9,600 or 19,200 bps
- RF data rate: 10,000 bps (@9,600 bps throughput data rate) or 20,000 bps (@19,200 bps)
POWER REQUIREMENTS
- XStream-PKG-R
- • Power supply voltage: 7 - 18V
- • Receive current:
- 70 mA @ 900 MHz
- 90 mA @ 2.4 GHz
- • Transmit current:
- 170mA@900MHz
- 180mA@2.4GHz
- • Power Down Current: < 1 mA
- XStream-PKG-U
- • Power supply voltage: 5 - 12V
- • Receive current:
- 90 mA @ 900 MHz
- 115mA@2.4GHz
- • Transmit current:
- 185 mA @ 900 MHz / -200 mA @ 2.4 GHz
- • Power Down Current: 50 mAXStream-PKG-T
- • Power supply voltage: 7 - 28V
- Receive current:
- 140mA@900MHz
- 160mA@2.4GHz
- • Transmit current:
- 220 mA @ 900 MHz
- 230mA@2.4GHz
- • Power down current: n/a
NETWORKING AND SECURITY
- Frequency: ISM 902 - 928 MHz or 2.4000 - 2.4835 GHz
- Spread Spectrum: FHSS (Frequency Hopping Spread Spectrum)
- Modulation: FSK (Frequency Shift Keying)
- Supported network topologies: Peer-to-peer (no master/slave dependencies), point-to-point, point-to-multipoint and multidrop
- Channel capacity (software selectable): 7 hopping sequences
- Network filtration layers: VID,Hopping Channel 8 Destination Address
CONNECTIONS OPTIONS
- RS-232/485 DB-9 (XStream-PKG-R)
- USB (XStream-PKG-U)
- Telephone RJ-11 (XStream-PKG-T)
DIMENSIONS
- XStream-PKG-R, XStream-PKG-U,
- Length: 6.99 cm *Width:13.97cm
- Depth: 2.86 cm
- Weight: 200.00 g
- XStream-PKG-T
- Length: 6.99 cm •Width: 16.51 cm
- Depth: 3.80 cm
- Weight: 228.00 g
ENVIRONMENTAL
- All models
- Operating temperature: 0° C to 70° C (commercial)
- Operating temperature: -40° C to 85° C (industrial)
CERTIFICATIONS
- FCC ID (U.S.Certification Pari 15.247)
- OUR-9XSTREAM (900 MHz),
- OUR-24XSTREAM (2.4 GHz)
- IC ID (Canada)
- 4214A-9XSTREAM (900 MHz),
- 4214A 12008 (2.4 GHz)
- Europe - ETSI, CE (2.4 GHz only)
ANTENNA
- Connector options: RPSMA (Reverse Polarity SMA)
- Impedance: 50 Ohms unbalanced
