Morrison - Model FIG 419 -Standard Drop Tube
Drop tubes are installed in the riser at the fill connection or attached to the bottom of overfill prevention valves to direct product flow from the fill point to within 6 inches of the tank bottom.
Most popular related searches
Standard Features
- Facilitates a submerged fill when properly installed
- Improves flow efficiency
- Reduces the build-up of vapors in the tank
- .062 wall thickness for durability
- Compatible with Morrison 539 diffusers
- Compatible with Morrison 9095A, 9095A-AV, 9095AA, and 9095C series overfill prevention valves
Construction Details
- Tube: Aluminum
- Gaskets: Buna-N
Certifications & Listings
CARB 95-19 (3″ and 4″ models), VR-402 (2″ and 3″ models)
