Dongli - Model GA107 MB -Strong base anion exchange resin
GA107MB is a high capacity, shock resistant, gel,Type I ,strongly basic anion exchange resin supplied in the chloride or hydroxide form as moist, uniform, spherical beads. GA107MB is intended for use in all type of deionization systems and chemical processing applications.Most popular related searches
anion exchange resin
strong base anion exchange resin
anion exchange
base anion exchange resin
strong base exchange resin
strong base anion resin
particle sizing
deionization system
deionizer system
gel type anion exchange resin
- Polymer Matrix Structure : Styrene Crosslinked with DVB
- Physical Form and Appearance : Clear spherical beads
- Whole Bead Count : 95% min.
- Functional Groups : R-N(CH3)3+
- Ionic Form ,as shipped ：CL
- Total Exchange Capacity, CL- form, wet, volumetric ： 1.30 meq/l min.
- Moisture Retention, CL- form ： 45-52%
- Particle Size Range ： 0.4-0.9mm
- Swelling CL-→ OH- ：18-20%
- Shipping Weight (approx.) ：670-720 g/
- Specific Gravity, moist CL- Form ：1.09
- PH Range, Stability ：0 - 14
- Maximum Temperature OH- Form ：60°C (140oF) max ；CL- Form ：80°C (176oF) max.
- Minimum Bed Depth ： 0.6m(24inches)
- Backwash Rate ： 50 to 75% Bed Expansion
- Regenerant Concentration ： 2 - 6%
- Regenerant Flow Rate ：2 to 8 BV/h (0.25 to 1.0gpm/cu/ft.)
- Regenerant Contact Time ：At least 40 minutes
- Regenerant Level ：112 -300g/L (4 to 10 pounds/ cu/ft.)
- Displacement Rinse Rate ：Same as Regenerant Flow Rate
- Displacement Rinse Volume ： 10 to 15 gallons/cu.ft.
- Fast Rinse Rate ： Same as Service Flow Rate
- Fast Rinse Volume ： 35 to 60 gallons/cu.ft.
- Service Flow Rate ：10-25m/h (2 to 10 gpm/cu/ft.)
