Sunmoy - Model 4SDM3 -4 Inch AC Deep Well Pump
SUNMOY AC deep well pump is a reliable and efficient water pumping solution. It is designed for extracting water from deep wells or boreholes. With its powerful motor and durable construction, it can reach significant depths and deliver a high flow rate. The pump is made of corrosion-resistant materials, ensuring long-lasting performance. It provides a dependable water supply for various purposes, including irrigation, livestock watering, and household use.
- Max. immersion depth: 80m
- Liquid temperature up to + 35°C
- Environmental temperature up to + 40°C
- Minimum well diameter: 4”
Suitable for use with dean water with a sand content of no more than 150 g/m3. As a result of their high efficiency and reliability they are suitable for use in domestic, civil and industrial applications such as for the distribution of water in combination with pressure sets, for irrigation, for washing plants and for pressure boosting in fire -fighting sets, etc.
- Pump Body: Stainless steel
- Motor Bracket: Stainless steel
- Impeller: Plastic. PPO
- Diffuser: Plastic. PC
- Motor Shaft: Stainless steel or 45# steel
- Mechanical Seal: Ceramic - graphite or Sic to graphite
- Electric Motor: Single-phase 220V/240 V 50 Hz with condenser and thermal overload protecto
- built Into the copper winding, equiped with start control box. Three -phase 380V/415V
- Insulation: Class B
- Protection: IP X8
