Super-Systems - Single-Loop Controllers
These process and high limit controllers are used for many thermal processing and indicating applications. The Series 7 has universal inputs with relays and analog outputs allowing for versatility and a wide range of monitoring or controlling applications. The panel mount unit offers high accuracy universal inputs for PID control and high limit protection.
Most popular related searches
7EK - 1/8 DIN Temperature Controller
- 1/8 DIN, Universal inputs
- 4 Relay outputs (P/N 31080)
- 1 Current (4-20mA) and 3 relay outputs (P/N 31081)
- 1 Slide-wire and 2 relay outputs (P/N 31082)
- Smart tuning function
- Modbus communications
- UL and cUL approved, CE marked
7SL - 1/16 DIN Overtemp High Limit
- 1/16 DIN, Universal inputs
- FM Relay Output + additional alarm relay output
- Modbus communications optional
- FM, UL, and cUL approved, CE marked
20Q Temperature Controller
- 1/4 DIN, Universal inputs (P/N 31091)
- Wide range of outputs (Relay, SSR, Triac, Servo)
- 11 logic inputs, 14 digital outputs, Clock / Calendar
- Smart tuning function
Modbus communications
- 3 row, 4 digit LED, 2 bar-graph LED display
- IP65, NEMA 4X
- 4 digital outputs,2 isolated mA outputs
- Remote setpoint input
- UL and cUL Approved, CE marked.
