ViaSat - Model 100 -Tank Level Monitoring Package
Complete tank level monitoring package includes satellite transceiver and ultrasonic tank level sensor. Turnkey solution with web-based data access. Access tank level data anytime, anywhere with an internet connection. Browse through thousands of tanks and their levels with SCADACore Live.
-
Monitoring for Tank Level, Water Level, and More
-
High and Low Level Notifications via SMS, Email, and / or Voice
-
Satellite Transceiver, Elevation angle: -5° to +90°
-
Input voltage: 9 to 32V
-
Power consumption: Receive: 65 mA; Transmit: 0.65 A; Sleep: 100 μA
-
Device Certifications: Class 1 Div 2, -40˚ C to +85˚ C
-
Device Dimensions: 12.6 cm x 12.6 cm x 4.9 cm
-
Pole Mount
-
Intrinsically Safe Ultrasonic Sensor
-
Sensor Range: 1 to 25 ft, 30.5cm to 762cm
-
Multi-sensor options available
-
Sensor mounting: 1 in., 2 in., or 3 in. NPT
-
Sensor Operating Temp: -30F to 140F, -35C to 60C
