Techno - Model CBI-309G -Cable and Metal Pipe Locator

Features CBI-309G

• Monoblock receiver AP-019.3 with built-in GPS/GLONASS module
• Visual indication of the utility axis on large LCD screen
• direct digital depth measurement up to 10 m
• Location of non-conductive and non-metallic utilities with optional pushing rod and pipe sonde

Brief description CBI-309G

• two modes of operation: “ROUTE” and “GRAPHIC”
• three inbuilt sensors make omnidirectional antenna showing a cable direction on large LCD display
• inbuilt sensor for digital measurement of the depth and current
• GPS/GLONASS module for accurate positioning of the located utility
• Mini-USB cable and desktop software for uploading and processing the data from the receiver.

Application CBI-309G

• Detection of energized cables underground up to 10 m
• Indication of the deviation from the utility axis
• GPS/GLONASS positioning of the located route
• Location of non-conductive and non-metallic utilities with optional pushing rod and pipe sonde

Standard set CBI-309G

• Receiver АP-019.3
• Battery alkaline R14 (4pcs.)
• Receiver bag
• CD with desktop software
• Mini-USB cable
• Operation manual
• Technical passport
