Tecval
TECVAL - Model VB-65 -2-Way 3-Pieces Full (FB) or Standard (SB) Bore Trunnion Ball Valve
FromTecval
2-Way 3-Pieces Full(FB) or Standard(SB) Bore Trunnion Ball Valve Working Pressure 160 bar (2286 PSI). TECVAL VB-65 trunnion ball valves are designed to work with liquids under either high pressure or moderate vacuum service. Due to their trunnion solid design, these valves withstand extreme service conditions where the strongest features are required. To be used in numerous applications, they are manufactured in several sizes, connections and alloys.
Most popular related searches
- Trunnion Ball.
- Quarter-turn actuation.
- Assembled three screwed pieces through 16 studs to allow a full disassembling on the spot.
- Full Bore (FB) or Reduced Bore (RB).
- Smooth operating.
- Easy cleaning and maintenance.
- No ejectable stem design.
- Anti-leak stem with double o-ring seal.
- 100% tested.
- Automation through electrical actuator.
- Automation through pneumatic actuator.
- Prepared for a quick automation (ISO 5211).
- Victaulic® connections.
- O-ring seals available in several materials.
