ZOGLAB - Model DSP1500 -Temperature and humidity probe
High accuracy with measuring range customized. Optional analog signal and digital signal. Single-point and multi-point calibration. Compatible with Rotronic and Vaisala`s probe command. Optional interface M12 , RJ45 and 8 wire. Toxicity and halogen free material , complying with GXP.
Most popular related searches
temperature and humidity probe
environmental instrument
flame retardant
humidity probe
NTC sensor
humidity generator
humidity temperature probe
temperature probe
humidity sensor
Measuring Data
- T Measuring Range: -30?~70? , -40?~60?(-40?~85? customized)
- T Accuracy: ±0.3?(23?±2?) , ±0.5?(FS)
- T Resolution: 0.1?/0.2?
- RH Measuring Range: 0%~100%RH
- RH Accuracy: ±3%RH(10%~85%RH) / other range ±5%RH(23?±2?)
- RH Resolution: 0.1%RH
General
- Power Supply: 5V~28V DC (0~5V 8V DC~28V DC 0~10V 14V DC~28V DC)
- Output Type: Analog signal: Voltage 0~1V / 0~2.5V / 0~5V / 0~10V , Digital signal: UART / RS485
- Interface: M12?RJ45?4 Wires
- Storage Temperature: -50?~90?
- ESP Protection: ±25KV
- IP Class: IP64
Sensing Probe
- T Sensor model: NTC
- H Sensor model: Humidity capacitance
General Feature
- Housing: ABS+PC,flame-retardant,toxicity and halogen free
- Dimensions: Φ15 x 110mm
- Wire: 2m / 3m / 5m (customized)
- Weight: 20g
