Luna T-Ray - Model 5600 and 5700 -Terahertz Control Units
The T-Ray® 5600 and 5700 are part of Luna's latest innovations in terahertz technology, designed for precision in waveform control, generation, and detection. The T-Ray 5600 is built upon a newly redesigned optical subsystem and advanced electronics that offer increased reliability and maintainability. It delivers high-speed processing up to 1,000 measurements per second, setting a benchmark in industrial terahertz systems. The T-Ray 5700 retains these high-performance capabilities and includes enhanced cybersecurity features. These products integrate seamlessly with industrial automation and robotics, ideal for thickness measurements, shape analysis, and density assessments. The TCU56xx in the same series supports a variety of sensors and gauges through robust interfaces, operable with T-Ray® Server Software. This latest model can be customized with multiple delay configurations for a wide range of measurement applications.
The T-Ray 5600 is the latest model in the Luna T-Ray® 5000 platform, offering enhanced reliability, maintainability, and performance through a complete redesign of its optical subsystems and advanced electronics. It provides precise terahertz waveform control, generation, and detection for fast, accurate measurements, with processing speeds up to 1,000 times per second, making it the fastest industrial terahertz system. The T-Ray® 5700 offers the same measurement capabilities, with added cybersecurity features.
Equipped with intelligent sensors and updated control units for seamless integration with industrial automation and robotics, both models are ideal for applications such as thickness measurements, extruded shape analysis, density and basis weight measurements, and ultra-high-speed measurements of moving samples.
The TCU56xx is the latest edition to the T-Ray® 5000 product line. The instrument comes standard with two channels and is available in multiple delay configurations to accommodate a broad set of measurement ranges. The TCU56xx is ideal for:
- High precision thickness measurements of single-layer and multi-layer materials and coatings
- Multi-point measurements of extruded shapes (ie OD, ID, concentricity, ovality, etc.)
- Density and basis weight measurements for a variety of materials
- Ultra high speed measurements of moving samples for online process monitoring and control
The TCU56xx is compatible with a variety of gauges and sensors that are connected via robust cabling and connection interfaces. Additionally, the powerful and user friendly T-Ray® Server Software enables the user to quickly and easily transform Terahertz signals into meaningful measurements. The system can be easily integrated with industrial automation and robotics through an abundance of communications protocols and I/O options.
- Ultra high speed measurements of moving samples for online process monitoring
- High precision thickness measurements of single and multi-layer material structures
- Dual optical channels for multiple simultaneous measurements in either reflection or transmission
- Powerful and user-friendly application oriented software platform
- Fiber coupled sensor allows product scanning via high flex umbilical cable
- Cost savings through improved process yields
- Simple user interface with independent measurement recipes
- Abundance of communication protocols and I/O options
- Provides measurement data in engineering units
- Easy integration with industrial automation and robotics
- Thickness measurement during coating application process
- Multi-point measurements of extruded tubing and shapes (ie OD, ID, concentricity, ovality, etc.)
- Top and bottom balance of steel and textile cord tire ply
- Density and basis weight measurements for multiple materials
- Quality inspection and non-destructive testing of coating thickness
- Listed solution for Class I Division 1 hazardous locations
