A.YITE - Model GE-327 -Thermal Flow Switches
FromZHOU ENSI LTD
GE-327 Thermal Flow Switch is based on two temperature sensors which are positioned within the fluid medium. The unheated sensor registers the liquid temperature. the other sensor is heated a few degrees above the medium, when the medium flows, the heat generated in the sensor is conducted away by the medium. The temperature of the sensor is measured and compared to the temperature of the medium. The state of flow can be derived by the temperature difference.Thermal Flow Controller Switches
Character of thermal flow switch:
* Remote connectivity, Easy integration
with centralized control systems
* No moving parts - no maintenance is needed
* One single model is good for multiple pipe size
* Compact design
* Low pressure loss
* LED displays flow trend and switching state
* 4-20mA and dual setpoint is available
* CE certification
Application of thermal flow switch:
* Circulating water system,
* Hydraulic and pneumatic system
* Pump run-dry protection.Output signal of thermal flow switMost popular related searches
