Comate - Model TGF450 -Thermal Mass Flow Meter
TGF450 thermal mass flow meter is a measurement solution specially designed for compressed air, nitrogen gas, oxygen. Provide a stable and accurate measurement at a more economical cost. The compact design and thick probe are easier to be installed under pressure pipeline with limited room.
Most popular related searches
thermal mass flow meter
mass flow metering
mass flow meter
thermal mass flow
flow meter
mass flow
mass flow monitoring
flow monitoring
compressed air
gas flow meter
- Minimum flow rate down to 0.3m/s, 1:100 super-wide turndown ratio
- Compressed air, Nitrogen, non-corresive flow measurement
- pulse and RS485 as a standard, Hart@4~20mA for option
- Hot tapping install, support isntall under pressure
- Bluetooth app offer very easy friendly operating interface
Ideal for compressed air system
- Specially designed for air and nitrogen mass flow measurements
- Anti-ejection, can be installed/removed under pressure
- Minimum flow rate down to 0.3m/s, 1:100 super wide turndown ratio
- No moving part, almost no pressure loss
- Direct mass flow measurement, free of temperature or pressure compensation
- Optimized power efficiency design, supper low power consumption down to 60mA@24VDC
- Standard output is pulse and RS485, Hart@4~20mA and 4~20mA is available
- Self-diagnose function with connected user’s phone via Bluetooth
