HYPER VALVES PVT. LTD.
HYPER VALVES - Thermal Relief Valve
Design: Angle type, Close bonnet Size: 1/2" to 2" Rating: Up to 2500# End Connection: Screwed, Socket Weld & Flange End Application : Liquid & Vapour Blow Down Pressure: 10% Less Then Of The Set Pressure. Hydrostatic Test Pressure: 1.5 Times The Set Pressure Overpressure: 10% Of The Set Pressure Orifice Designation: As per API Material: WCB, WC1, WC6, WC9, LCB, LCC, LC3, C5, C12, CF8, CF8M, CF3, CF3M,CF8C, CN7M, CD4MCu, Inconel, Duplex steel 4A, 5A, 6A, aluminium bronze, hastelloy cMost popular related searches
relief valve
safety relief valve
thermal relief valve
hydrostatic pressure testing
tightness testing
hydrostatic test
hydrostatic testing
angle valve
product safety
- Design Standard: API 520
- Performance Standard: API 526
- Seat Tightness Test: API 527
- End Connection: Screwed To ASME B 1.20.1, Socket Weld To ASME B 16.11, Butt Weld To ASME B16.25, Flanged To ASME B 16.5
- Spring Loaded Safety Relief Valve
- Full Lift Pop Action Design
- Closed Bonnet With Pack Lever
- Stellited Nozzle & Disc Seating Area
