INOMETA PROTEK - Thermal Sprayed Ceramic Coatings

Thermal sprayed ceramic coatings are specialized coatings made of ceramic materials. These coatings are applied to surfaces such as CFRP/GFRP rollers or aluminium components to protect them from extreme temperatures and/or abrasive environments.

Our PROTEK ceramic coatings made of titanium, aluminium, and chromium oxides are particularly resistant to frictional and sliding wear, offering outstanding wear protection when guiding films, fibers, paper, and cardboard. Defined surface structures ensure reliable entrainment and air removal, while ground coatings achieve optimal sliding properties. In addition, hydrophilic or hydrophobic properties can be realized depending on the processing stage.
By using advanced processes and high-quality materials tailored to your specific requirements, we ensure optimum performance and reliability for your application.

Specially developed for a wide range of industries, our PROTEK^® ceramic coatings offer first-class protection and functionality. Through our dedication to quality and innovation, we collaborate with you to develop customized solutions that perfectly meet your specific needs and propel your business forward. Our PROTEK^® ceramic coatings are used in a wide range of applications, including:

• Printing industry – base layer of anilox rollers in flexographic and gravure printing processes
• Textile industry – dry lead rollers
• Film industry – laminating rollers, corona rollers
• Printing industry – doctor blades
• Steel industry – rollers & slewing bearings, continuous casting molds
• Chemical industry – pumps, agitators, plain bearings
• Battery cell production – guide rollers, deflection rollers
• Fuel cell production – guide rollers, deflection rollers

PROTEK^® ceramic coatings are distinguished by a range of unique features and benefits that make them ideal for a wide variety of applications in diverse industries, contributing to enhanced efficiency and profitability for your operations:

• High temperature resistance – can be used up to 1200 °C and more
• Good thermal conductivity – provides protection for substrates against external heat exposure
• Wear resistance – resistant to abrasive wear, erosion, adhesion and fretting
• Corrosion resistance – resistant to material degradation caused by aggressive media
• Electrical insulating properties
• Hardness from 700 up to 1300 HV 0.3 and high dimensional stability – high resistance to mechanical loads
• Pressure resistance – stable under high pressure conditions
• Chemical resistance – resistant to various chemicals
• Resistant to friction and sliding wear – hydrophilic or hydrophobic properties can be mapped depending on the processing stage
• Traction properties and sliding behavior invariable
• Low surface energy
• Increased production speed without compromising on quality
• Minimization of machine downtimes

Through continuous innovation in thermal spraying, we deliver optimal protection against static, dynamic, mechanical, and chemical loads for a variety of components. Our advanced processes provide a vast selection of base and coating material combinations, ensuring a perfect fit for your specific application needs.

For CFRP/GRP, aluminium, and steel rollers, we offer thermal coating processes such as:

• High velocity oxygen fuel spraying (HVOF)
• Arc spraying with atomizing gases like nitrogen or argon
• Thermal spraying

These coating methods are employed to apply PROTEK^® ceramic coatings, enhancing the performance of customer-oriented applications. The advantages of thermal spraying include:

• High adhesive strength of the coating
• Minimal substrate distortion
• Ability to coat complex geometries
• Wide range of coating materials
• Enhanced surface properties
• High coating thicknesses
• Corrosion and wear resistance
• High- temperature resistance
• Thermal conductivity
• Electrical insulation properties
• FTA-compliant
