DSG-Canusa - Model CHM 140 -Thin Wall Semi-Rigid Crosslinked Polyolefin Heat Shrink Tubing
CHM 140 is a semi-rigid heat shrink tubing specifically designed for use in industrial, military, aerospace, and commercial applications where exceptional strain relief is crucial. It is engineered to offer physical protection for electronic components and strain relief of terminals. The tubing features a 2:1 and 2.5:1 shrink ratio, making it versatile for various applications. Designed to be used with automatic feed equipment, CHM 140 aligns with standards such as SAE-AMS-DTL-23053/6, ensuring reliable performance in demanding environments. Its semi-rigid nature makes it ideal for environments requiring durability and precision, providing protection and insulation in harsh conditions.
CHM 140 is a semi-rigid heat shrink tubing for use with automatic feed equipment or other industrial, military/aerospace and commercial applications requiring exceptional strain relief.
- 2:1 shrink ratio and 2.5:1 shrink ratio
- Exceptional mechanical strength and abrasion resistance
- Semi-rigid
- Flame retardant
- Thicker wall available for additional mechanical protection
- Resistant to acids, alkalis, hydrocarbon solvents and hydraulic fluids
- Continuous operating temperature: -55°C to 135°C
- Shrink temperature: 135°C
- UL 224 125°C
- CSA C22.2 No. 198.2 (2.5:1 shrink ratio sizes only)
- SAE AMS-DTL-23053/6, (colors)
- AMS 3638 and 3639
- UL/CSA approval applies to Black only
- Physical protection of electronic components, strain relief of terminals
- OEM
- Industrial
- Aerospace Defense
- Select a dimension which will shrink snugly over the component to be covered. If recovery is restricted the resulting wall thickness will be less than specified.
- Select Options:
- Color: Black (BK)
- Lengths: 48 in (1.2 m) continuous reels or cut pieces
- Please specify the product name, order number and options you require.
- Order Example: CHM 140, 0375, black, unprinted, 500 ft reel
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
