Tiandi - Polyimide Acrylic Tape
Polyimide Acrylic tape is polyimide film coated with heat-resistant acrylic adhesive . It offers excellent properties of heat resistance, electrical insulation, solvent resistance and radiation protection. It is innocuity and has no abnormal smell, so it cause no damage to operators and the environment. It is widely used in electronic and electric field. Insulation class is F.
Most popular related searches
Acrylic Polyimide Film Adhesive Tape Applications
- Mask in the electronic assembly
- High temperature powder coating
Acrylic Polyimide Film Adhesive Tape Specifications
- Breakdown Voltage: 7 KV
- Bond Strength: 6.2 N/25mm
- Tensile Strength: 135 N/25mm
- Elongation at rupture: 30 %
- Operation temp. :155 °C
Product Available
- Width:: Upon requirements
- Color: Amber
- Thickness: 0.06mm (Pl:0.025mm, Acrylic: 0.035mm)
