Fuqi - Titanium Welded Reducing Tee
Grade: Titanium Gr2 / UNS R50400. OD: DN6 - DN1100; 1/8" - 44"; 10 -1117.6mm. Type: titanium welded tee. Type1: titanium reducing tee. Thickness: Sch5s, Sch10s, Sch40s, STD, Sch40, Sch60, Sch80s, Sch80. Surface Treatment: CNC Machined Polished. Material Standard: ASTM B862. Welding Method: TIG, GTAW. Welding Line: 2 welding lines, 1pc welding line tee available. Elbow Standard: Customized, based on ASME B16.9, produced by detail drawing. We provide free detail drawing as customer's request dimension.
Most popular related searches
Welding Process (TIG Preferred) of titanium welded tee
- Tungsten Inert Gas (TIG/GTAW) is the most common method for titanium.
- Tungsten Electrode: Use a sharpened thoriated or lanthanated tungsten (2% thoriated is common).
- Filler Metal: Match the base metal grade (e.g., ERTi-2 for Grade 2).
- Shielding Gas: High-purity argon (or argon/helium mix) with a flow rate of 15-20 CFH.
