Metstar - Model TWP16 -Troposphere Radar Wind Profiler
The wind profile radar system plays an important role in short-term weather forecasting, airport air traffic safety, missile and shell control, weather modification, and meteorological scientific research
Most popular related searches
wind profiling
wind profiling radar
radar wind profiling
wind speed monitoring
wind monitoring
scientific research
pulse-doppler
radar system
weather forecasting
wind profiling system
- Technology: P-band fully coherent pulse Doppler system
- Operating frequency: 445MHz/480MHz
- Height of detection- maximum: >12km
- Height of detection- minimum: 240m
- Measurement range: Wind speed measurement range: 0~80m/s, Wind direction measurement range: 0~360°
- Measuring error (root-mean-square deviation): Wind speed measurement error: <1.5m/s, Wind direction measurement error: <10°
- Height resolution: 120m/240m
- Time resolution: Standard observation mode,3 beam ≤3min, 5 beam <5min
- Radial velocity resolution: ≤0.2 m/s
- Accuracy of wind speed measurement: <1.5 m/s (RMS)
- Accuracy of wind direction measurement: <10° (wind speed >5m/s)
- MTBF: >4400 hours
