GEI Works - Model Type 2 -Turbidity Curtain for Water with Currents
The Type 2 Turbidity Curtain, also known as a Silt Barrier, is specifically engineered for aquatic environments with moderate movement, such as currents, waves, and tides. Manufactured in the USA, this floating barrier is constructed using high-quality components designed to effectively contain turbidity and displaced materials within a specified zone. Ideal for areas experiencing waves up to two feet and currents reaching 2 knots, the Type 2 Turbidity Barrier is available in both permeable and impermeable options, with material choices of 18 oz and 22 oz. The system incorporates a top tension cable and ASTM universal slide connectors, ensuring robust and adaptable installation. Through various anchoring options, the curtain provides reliable, adjustable containment solutions tailored to dynamic water conditions.
Type 2 Turbidity Curtain also known as Silt Barrier, is a floating turbidity curtain designed specifically for areas with moving water, currents, waves, or tides. Manufactured in the USA with high-quality reliable components, Type 2 Silt Curtains contain turbidity and displaced particles in a designated area. Type 2 Turbidity Barriers are recommended for use in water locations with waves up to two feet (2′), moderate wind, and currents up to 2 knots.
- Perfect for short term and long term projects in moving water with moderate wind.
- A favorite for DOT sites, roads, and areas around DOT projects.
- Dredging Projects
- Pile Driving
- Shoreline Construction
- Boat Ramp Creation
- DOT Roadwork and Construction Projects
- Dock Repair, Demolition and Maintenance
- Rip Rap Installation
- Remediation Projects
- Float Size: 6″ or 8″ Floats
- Material: 18 oz. Impermeable PVC
- Top Cable: 5/16″ Top Tension Galvanized Cable
- Ballast: 5/16″ Bottom Ballast Chain
- Reinforced Grommet Section Connectors
- Anchor Point: Eye Bolt Anchor Point (every 50 ft.)
- Float Size: 6″, 8″ or 12″ Floats
- Material: 22 oz. Impermeable PVC
- Top Cable: 5/16″ Top Tension Galvanized Cable
- Ballast: 5/16″ Bottom Ballast Chain
- Connectors: ASTM Universal Slide Connectors
- Anchor Point: Eye Bolt Anchor Point (every 50 ft.)
- Float Size: 6″, 8″ or 12″ Floats
- Material: 22 oz. Impermeable PVC with Permeable Monofilament Filter Fabric
- Top Cable: 5/16″ Top Tension Galvanized Cable
- Ballast: 5/16″ Bottom Ballast Chain
- Connectors: ASTM Universal Slide Connectors
- Anchor Point: Eye Bolt Anchor Point (every 50 ft.)
- Anchor Kits: Anchoring is crucial for the success of your project. Without proper anchoring your Turbidity Barrier will fail. (USACE suggests anchors every 50′ contingent on site and water conditions)
- Tow Bridles: Tow Bridles help distribute weight and prevent damage during deployment and adjustment.
- Accessories are an important component for the silt curtain installation. Click the link above to Learn more about these Type II silt curtain accessories, their specs, and uses. View our Ground Anchor Installation and Silt Curtain Anchoring Instructions.
