Inwet - Model GT-Type -Turbine Pneumatic Vibrators

Properties:

• no lubrication needed,
• low level of noise,
• high running torque and high amplitude
• revolutions frequency from 6 300 to 46 000 min-1,
• exciting force from 135 to 12 000 N,
• limited air consumption,
• max. working temp. 150°C,
• harsh conditions resistant.

Construction:

• circular vibrations produced by an unbalanced turbine set on bearings,
• dry air supply,
• turbine set on two bearings which provide long life.

Usual applications:

• silo and chute emptying,
• screens,
• vibrating tables,
• protecting tube or chute walls from material sticking,
• bulk products transportation,
• condensing or loosening bulk materials in containers.
